Steel Stud Profile Roll Former for Modular Wall Partitions

This roll forming line produces C‑channel profiles used as framing for modular office partitions, drywall systems, and interior walls. The machine forms 0.5‑1.2mm galvanized steel coil into C‑sections with punched service holes and knockouts for electrical wiring. Integrated punching creates screw attachment slots. Speeds up to 20 m/min, cut‑off tolerance ±0.5mm. Quick changeover between stud widths (50‑150mm) and lengths. Ideal for partition manufacturers and drywall contractors requiring lightweight, strong metal framing.

Brand: SAVANY
Machine Type: Roll forming machine / Press brake / Custom production line
Color: Custom / Customizable
Capabilities: Roll forming, punching, shearing
Roll Forming Material: SPCC/SPCD/SPCE/SGCC/CGCC/304/5052
Profile Dimensions: Custom
Customization Level：100% custom
Payment Terms: T/T
Lead Time: 90 working days
Place of Origin: Guangdong, China

Contact Us

Description

C‑Channel Partition Frame Rolling Forming Machinery

– Lightweight Framing for Modular Walls

The C‑channel partition frame roll forming machine is designed to produce steel studs (C‑profiles) used in modular office partitions, drywall systems, and interior wall framing. These profiles are lightweight, fire‑resistant, and provide a strong framework for attaching gypsum boards or other cladding.

Why roll forming for partition frames?

Traditional wooden studs are susceptible to warping, fire, and insects. Steel studs are dimensionally stable, non‑combustible, and recyclable. Roll forming produces continuous lengths of C‑profile with pre‑punched service holes, eliminating on‑site cutting and drilling.

Production process:

Uncoiling – Motorized uncoiler (5‑10 tons), coil width 100‑300mm.
Straightening – Leveling rolls.
Servo punching – Creates service holes (for electrical wiring, plumbing), knockouts, and screw attachment slots.
Roll forming – 12‑14 passes form the flat strip into a C‑channel. Rollers Cr12MoV, HRC58‑62.
Notching (optional) – Creates corner notches for frame assembly.
Cut‑off – Flying shear cuts to length (±0.5mm).
Stacking – Automatic stacker.

Key features:

High speed – Up to 20 m/min, producing thousands of studs per shift.
Service holes – Pre‑punched for easy wiring and plumbing.
Lightweight – Thin gauge reduces material cost and handling effort.
Quick changeover – Adjustable tooling for stud widths from 50‑150mm.
Fire resistant – Steel does not burn.

Material range:

Galvanized steel (SGCC)
Cold‑rolled steel (for painting)
Thickness: 0.5‑1.2mm

Typical C‑channel sizes:

Parameter	Range
Stud width	50‑150 mm
Flange height	25‑40 mm
Material thickness	0.5‑1.2 mm
Service hole size	25‑50 mm
Line speed	15‑20 m/min
Cut‑off tolerance	±0.5 mm

Applications:

Office partition framing
Drywall studs for interior walls
Modular building frames
Ceiling grid supports
Industrial partition walls

Optional features:

Notching for corner joints
Embossing for reinforcement
Automatic counting and bundling

Included services:

Installation guidance
Operator training
Spare parts list
12‑month warranty, lifetime remote support

Lead time: 75‑90 working days after deposit and drawing confirmation.

Contact SAVANY with your C‑channel drawing (width, thickness, hole pattern) for a customized quotation.

➤
