Corrugated Sheet Roll Forming Machine – Custom Roll Forming Machine Manufacturer

Metal Roofing & Cladding Panel Roll Forming Equipment for Construction

This roll forming machine produces corrugated (wavy) steel sheets for roofing, wall cladding, and industrial siding. The line forms 0.3‑0.8mm galvanized or pre‑painted steel coil into standard corrugations (e.g., 18‑76‑18, 35‑175, etc.). Integrated cutting and stacking. Speeds up to 30 m/min, cut‑off tolerance ±1mm. Quick change between wave patterns. Optional embossing for anti‑slip or decorative finishes. Ideal for building material suppliers, agricultural sheds, and industrial roofing contractors.

Brand: SAVANY
Machine Type: Roll forming machine / Press brake / Custom production line
Color: Custom / Customizable
Capabilities: Roll forming, punching, shearing
Roll Forming Material: SPCC/SPCD/SPCE/SGCC/CGCC/304/5052
Profile Dimensions: Custom
Customization Level：100% custom
Payment Terms: T/T
Lead Time: 90 working days
Place of Origin: Guangdong, China

Contact Us

Description

Corrugated Sheet Cold Rolling Forming Machinery

– Versatile Profiles for Roofing and Cladding

The corrugated sheet roll forming system is a high‑speed line for manufacturing sinusoidal (wave‑shaped) metal sheets used in roofing, wall cladding, and fencing. Corrugated sheets offer excellent strength‑to‑weight ratio and are widely used in agricultural, industrial, and residential construction.

Why roll forming for corrugated sheets?

Press braking cannot produce continuous wave patterns. Roll forming is the only efficient method for long‑length corrugated sheets, providing consistent wave height, pitch, and straightness.

Production process:

Uncoiling – Motorized uncoiler (5‑10 tons), coil width up to 1250mm.
Straightening – Leveling rolls.
Roll forming – 12‑18 passes gradually form the wave pattern. Rollers are precision‑ground to the specific wave shape.
Embossing (optional) – Adds stiffening ribs or decorative patterns.
Cut‑off – Hydraulic or flying shear cuts to length (±1mm).
Stacking – Automatic stacker with counting.

Key features:

High speed – Up to 30 m/min, producing thousands of square meters per shift.
Standard wave patterns – 18‑76‑18, 35‑175, 40‑160, and custom waves.
Heavy‑duty construction – Rigid frame for stable forming.
Quick changeover – Tooling sets for different wave profiles.
Material versatility – Steel, aluminum, or stainless steel.

Material range:

Galvanized steel (SGCC)
Pre‑painted steel (PPGI)
Aluminum
Thickness: 0.3‑0.8mm

Typical wave patterns:

Profile	Wave pitch	Wave height	Application
18‑76‑18	76 mm	18 mm	Roofing, siding
35‑175	175 mm	35 mm	Heavy‑duty roofing
40‑160	160 mm	40 mm	Industrial cladding
Custom	any	any	Special orders

Applications:

Agricultural building roofing
Industrial shed walls
Residential roofing (covered with tiles)
Fencing panels
Container floors

Optional features:

In‑line notching for end cuts
Automatic stacking with plastic interleaving
Embossing for wood grain or stone texture

Included services:

Installation guidance
Operator training
Spare parts list
12‑month warranty, lifetime remote support

Lead time: 75‑90 working days after deposit and drawing confirmation.

Contact SAVANY with your corrugated sheet drawing (wave pattern, thickness, width) for a customized quotation.

➤
