Warehouse Shelving Deck & Riveted Shelf Roll Former

This roll forming line produces steel shelf panels (decks) for pallet racks, warehouse shelving, and riveted storage systems. The machine forms flat or ribbed panels from 0.5‑1.5mm galvanized steel coil with integrated punching for shelf support hooks and stiffening ribs. Embossing adds reinforcement patterns to increase load capacity. Cut‑off tolerance ±0.5mm ensures precise fit. Speeds up to 15 m/min. Quick changeover between panel widths (300‑1200mm). Ideal for rack manufacturers needing high‑quality, consistent shelf panels.

Brand: SAVANY
Machine Type: Roll forming machine / Press brake / Custom production line
Color: Custom / Customizable
Capabilities: Roll forming, punching, shearing
Roll Forming Material: SPCC/SPCD/SPCE/SGCC/CGCC/304/5052
Profile Dimensions: Custom
Customization Level：100% custom
Payment Terms: T/T
Lead Time: 90 working days
Place of Origin: Guangdong, China

Contact Us

Description

Steel Shelf Panel Cold Rolling Equipment

– Strong, Flat Decks for Any Storage System

The steel shelf panel roll forming machine is designed to produce shelf decks (panels) for pallet racks, industrial shelving, and riveted storage systems. Shelf panels must be flat, dimensionally accurate, and have precisely placed hooks or holes for shelf support clips. Our roll forming line delivers all these requirements in a single continuous process.

Why roll forming for shelf panels?

Traditional shelf manufacturing involves cutting sheets, punching holes, and bending edges on a press brake – multiple steps with high labor and inconsistent results. Roll forming produces shelves with consistent flatness, accurate hole locations, and optional stiffening ribs – all in one pass.

Production process:

Uncoiling – Motorized uncoiler (5‑10 tons), coil width up to 1250mm.
Straightening – Leveling rolls ensure flat material.
Servo punching – Creates mounting hooks, support slots, and wire management holes. Programmable patterns.
Embossing (optional) – Adds longitudinal ribs to increase load capacity by up to 40% without increasing thickness.
Edge forming – Hemmed front edge (folded double layer) for safety and rigidity.
Roll forming – Final flatness and straightening.
Cut‑off – Flying shear cuts to exact panel depth (±0.5mm).
Stacking – Automatic stacker collects finished panels.

Key features:

Flatness guaranteed – Straightener and post‑forming leveling ensure shelves are perfectly flat, preventing sagging.
High strength – Ribbed panels support up to 100kg evenly distributed.
Precise hole placement – Servo‑controlled punching ±0.3mm accuracy ensures hooks align perfectly.
Quick changeover – Adjustable tooling for panel widths from 300mm to 1200mm.
Surface protection – Suitable for pre‑finished and laminated steel.

Material range:

Cold‑rolled steel
Galvanized steel (SGCC, DX51D)
Pre‑painted steel
Thickness: 0.5‑1.5mm

Typical shelf panel dimensions:

Parameter	Range
Panel width	300‑1200 mm
Panel depth	400‑1200 mm
Material thickness	0.5‑1.5 mm
Rib depth	5‑10 mm
Edge hem	10‑15 mm
Line speed	10‑15 m/min
Cut‑off tolerance	±0.5 mm

Load capacity:

Flat shelf (no ribs): up to 50kg
Ribbed shelf: up to 100kg
Heavy‑duty ribbed (1.5mm): up to 150kg

Applications:

Pallet rack shelf decks
Riveted shelf panels
Perforated shelves (with optional hole punching)
Wire mesh shelf decking (with special tooling)
Industrial shelving for warehouses

Optional features:

Perforated hole punching for ventilation or wire mesh
Label holder embossing
Divider slot punching
Automatic stacking with counting

Included services:

Installation guidance
Operator training
Spare parts list
12‑month warranty, lifetime remote support

Lead time: 75-90 working days.

Contact SAVANY with your shelf panel drawing (width, depth, thickness, rib pattern, hole locations) for a customized quote.

➤
